Heavy Duty Shaftless Rotogravure Printing Machine

Get a Price/Quote

MOQ : 1 Unit

Heavy Duty Shaftless Rotogravure Printing Machine Specification

Type
Heavy Duty Shaftless Rotogravure Printing Machine

Material
Mild Steel, Stainless Steel, Aluminium

Capacity
Up to 120 m/min

Computerized
Yes

Automatic Grade
Automatic

Plate Type
Rotogravure Cylinder

Control System
PLC & Touch Screen Interface

Power
32 kW

Size
Customizable

Weight (kg)
8000 kg (Approx.)

Dimension (L*W*H)
9500 mm x 3200 mm x 2800 mm

Drive system
AC Servo Motor

Voltage
380V/415V, 3 Phase, 50/60Hz

Noise Level
80 dB

Ink Circulation
Auto Ink Circulation with Viscosity Control

Cylinder Changing
Shaftless Pneumatic System

Unwinding/Rewinding Diameter
Max 1000 mm

Registration Accuracy
0.1 mm

Safety Features
Emergency Stop, Interlock System

Web Handling
Automatic Tension Control

Drying System
Hot Air & IR Dryers

Heavy Duty Shaftless Rotogravure Printing Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Against Delivery (CAD)

Supply Ability
Unit

Delivery Time
2 Months

Packaging Details
Open Packaging.

Main Export Market(s)
Australia, Eastern Europe, Middle East, Western Europe, Africa, Central America, South America, Asia, North America

Main Domestic Market
All India

About Heavy Duty Shaftless Rotogravure Printing Machine

Shaftless Rotogravure Printing Machine
Heavy Duty Shaftless Rotogravure Printing Machine (High speed Machine) speed upto 200 mtr/min. in Multicolours. Flotter type (Shaftless) unwind and rewind with 5 Drive A.C moter system with synconisation panel.

Advanced Drying System

Featuring integrated hot air and IR dryers, this machine provides rapid and even ink drying, supporting high-speed production without compromising print quality. The drying systems accommodate diverse ink formulations and substrates, ensuring consistent and vibrant results across long runs.

Intelligent Web Handling & Precision

Automatic tension control and a registration accuracy of 0.1 mm minimize material waste and guarantee perfect alignment, whether working with flexible packaging or labels. The computerized control system optimizes performance for demanding printing applications.

Customizable & User-Friendly Design

The machines shaftless pneumatic cylinder changing, PLC touchscreen interface, and AC servo drive system allow for effortless operation and maintenance. Customizable dimensions and capacity make integration seamless for varied production needs, while robust safety and interlock systems prioritize operator protection.

FAQs of Heavy Duty Shaftless Rotogravure Printing Machine:

Q: How does the shaftless pneumatic cylinder changing system enhance production efficiency?

A: The shaftless pneumatic cylinder changing system enables quick and simplified cylinder swaps without requiring manual shaft installation. This reduces downtime during job changes and improves overall production throughput by streamlining the setup process.

Q: What benefits does the automatic tension control offer during web handling?

A: Automatic tension control maintains consistent web tension throughout the printing process, minimizing material wastage and avoiding print misalignment. This feature ensures precise registration and high-quality output across varying substrate types and thicknesses.

Q: When should the hot air and IR dryers be used in the printing process?

A: Hot air and IR dryers are employed after each print station to thoroughly dry inks on substrates. The combination of both drying technologies ensures complete ink curing, which is particularly advantageous during high-speed runs or when using specialty inks that require rapid and uniform drying.

Q: What safety features are incorporated in the Heavy Duty Shaftless Rotogravure Printing Machine?

A: This machine is equipped with emergency stop buttons and an interlock system to protect operators from potential hazards. These safety mechanisms shut down operations instantly in the event of an emergency and prevent unauthorized access during critical functions.

Q: Where can this rotogravure printing machine be installed, and is its size adaptable?

A: Designed for industrial settings, the machines robust build and customizable dimensions accommodate diverse production environments. Manufacturers and suppliers in India can specify the required size and configuration to match their operational footprint.

Q: What role does the auto ink circulation with viscosity control play in maintaining print consistency?

A: Auto ink circulation with viscosity control ensures that ink properties remain stable throughout production, preventing print defects caused by ink thickening or thinning. This automated system supports uninterrupted operation while delivering uniform print quality.
