Solvent Based Lamination Machine

Get a Price/Quote

MOQ : 1 Set

Solvent Based Lamination Machine Specification

Max Lamination Temp
120C

Membrance Core Size
3 (76 mm)

Max Film Width
1300 mm

Material
Mild Steel (MS)

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control

Drive Type
AC Drive

Heating System
Hot Air / Electric

Power Source
Electric

Voltage
380V / 415V

Weight (kg)
3500 kg

Dimension (L*W*H)
6800 x 3200 x 2400 mm

Capacity
250 m/min

Feature
High Speed, Energy Efficient, Robust Construction

Color
Blue & Silver

Type of Rollers
Rubber & Steel Rollers

Speed
Up to 250 meters/min

Input Paper Size
Up to 1300 mm

Suitable Paper
BOPP, PET, CPP, Metalized Films, Paper

Gluing Type
Solvent Based Adhesive Application

Unwind/Rewind Units
Double Shaft Auto Tension Control

Roller Surface Finish
Hard Chrome Plated

Safety Features
Emergency Stop, Safety Guards

Operator Panel
Touch Screen Interface

Web Guide System
Automatic Edge Alignment

Noise Level
Low Noise Operation (<80 dB)

Laminating Accuracy
±0.5 mm

Adhesive Applicator
Gravure Roller System

Main Motor Power
15 kW

Solvent Based Lamination Machine Trade Information

Minimum Order Quantity
1 Set

Payment Terms
Cash Against Delivery (CAD)

Supply Ability
Set

Delivery Time
2 Months

Packaging Details
Open Packaging.

Main Export Market(s)
Australia, North America, Eastern Europe, Middle East, Western Europe, Africa, Central America, South America, Asia

Main Domestic Market
All India

About Solvent Based Lamination Machine

We are leading manufacturer and supplier of solvent based coating and lamination machine in different models like standard model and high speed model speed upto 200 mtr./min. suitable for the lamination of flexible packaging i.e polyester to met. polyester, polyester to poly, bopp to met, polyester to paper, paper to alum. foil for the lamination of different material for flexible packaging pouches & bags, rice and atta bags etc.

High-Speed Precision Lamination

Designed for industrial laminating operations, this machine achieves speeds of up to 250 meters per minute while maintaining 0.5 mm accuracy. Automatic tension control and web alignment guarantee uniform lamination, reducing material waste and rework. Its reliable performance makes it ideal for demanding environments.

Efficient Adhesive Application

Utilizing a gravure roller system for solvent-based adhesive application, the machine ensures consistent coating across various substrates such as BOPP, PET, CPP, metalized films, and paper. The hot air/electric heating system optimizes curing and reduces drying time, supporting seamless lamination even at maximum speeds.

Operator-Friendly & Safe Design

The intuitive touch screen interface and computerized PLC control system simplify operation and monitoring, while manual interventions are minimized. Equipped with safety features like emergency stop and safety guards, along with low noise operation (<80 dB), it ensures a safe, comfortable working environment.

FAQs of Solvent Based Lamination Machine:

Q: How is adhesive applied in the Solvent Based Lamination Machine?

A: Adhesive is precisely applied using a gravure roller system, which ensures even distribution of solvent-based adhesives across the material. The system is optimized for high-speed operation, enabling consistent and reliable lamination.

Q: What types of substrates can this lamination machine process?

A: This machine is versatile and can handle materials such as BOPP, PET, CPP, metalized films, and various paper grades with a maximum film width of 1300 mm, making it useful across packaging and printing industries.

Q: When is it recommended to use a solvent based adhesive application in lamination?

A: Solvent-based adhesive application is preferred when high bonding strength, fast curing, and superior flexibility are requiredespecially for complex laminates or demanding industrial environments.

Q: Where is the Solvent Based Lamination Machine typically installed and operated?

A: It is widely used by manufacturers, suppliers, and traders in Indias packaging, printing, and converting factories that require robust, high-speed lamination equipment.

Q: What level of accuracy does the lamination process achieve?

A: The machine offers laminating accuracy within 0.5 mm, supported by features like auto tension control and automatic edge alignment, delivering dependable consistency for quality-critical applications.

Q: How does the control system enhance the usage experience?

A: A computerized PLC control system with touch screen panel allows real-time monitoring and adjustment, streamlining operations and reducing downtime. Safety functions such as emergency stop and guards further protect operators.

Q: What are the benefits of using this lamination machine in production?

A: Benefits include high processing speed (up to 250 m/min), energy efficiency, robust construction, low noise emission, accurate tension and alignment controls, and adaptability to multiple substrate types, all contributing to cost-effective, high-quality output.
