Paper Coating Machine

Get a Price/Quote

MOQ : 1 Piece

Paper Coating Machine Specification

Product Type
Paper Coating Machine

General Use
Paper coating applications in various industries

Material
Mild Steel, Stainless Steel Contact Parts

Type
Automatic

Weight (kg)
3500 kg

Coating Head
Knife over roll

Coating Width
Up to 1600 mm

Coating Material
Paper, board, film

Computerized
Yes

Automatic
Yes

Control System
PLC Control

Power Source
Electric

Heating System
Electric or thermal oil

Drive Type
AC variable frequency drive

Voltage
380V / 415V / 440V, 3 Phase

Humidification System
Yes

Rewinder Type
Automatic surface center rewinder

Unwinder Type
Hydraulic shaftless unwinder

Dimension (L*W*H)
12000 mm x 2250 mm x 2450 mm

Feature
High precision coating, automatic control, energy efficient

Color
Blue and White

Tension Control
Automatic tension control

Core Diameter
76 mm (3 inch) / 152 mm (6 inch)

Max Roll Diameter
1200 mm

Noise Level
Below 80 dB(A)

After Sales Service
Available worldwide

Operator Interface
Touch panel HMI

Web Guide System
Automatic edge guiding

Operating Temperature
Up to 180°C

Installation Support
Provided

Safety Features
Emergency stop, safety covers

Paper Coating Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Against Delivery (CAD)

Supply Ability
Piece

Delivery Time
2 Months

Packaging Details
Open Packaging.

Main Export Market(s)
North America, Eastern Europe, Western Europe, Africa, Middle East, South America, Asia, Central America, Australia

Main Domestic Market
All India

About Paper Coating Machine

Backed by rich industry experience and knowledge, we have been able to manufacture and supply a broad range of Paper Coating Machine. Offered machine is tested on various predefined quality parameters to assure its hassle free performance. This machine is customized according to the needs of the clients in different technical specifications. Provided machine is manufactured under the vigilance of talented experts using premium quality components in accordance with market prevailing quality standards. Additionally, this Paper Coating Machine is available to the clients at competitive prices.

Features:

Hassle free performance
Anti-corrosive body
Sturdy construction
Easy to use

Precision Engineering for Industrial Coating

Designed for versatility and accuracy, this paper coating machine suits various industries seeking reliable, high-quality coated products. Advanced control systems and automatic features minimize human error, while the knife-over-roll coating head ensures consistent, uniform application. A robust humidification and heating system supports precise control of coating properties, optimizing production output.

User-Centric Automation and Safety

Equipped with a PLC-controlled operator interface and touch panel HMI, operation is intuitive and user-friendly. Automatic tension and edge guiding systems enhance productivity, while comprehensive safety featuressuch as emergency stops and safety coversprioritize operator well-being. The noiseless design further improves the working environment for users.

Comprehensive Support Worldwide

Installation support is provided for seamless setup. The manufacturer offers dependable after-sales service to ensure the long-term reliability and peak performance of your coating machine, regardless of location. With global service capabilities and a reputation as a trusted supplier in India, customers can be assured of responsive assistance and professional care.

FAQs of Paper Coating Machine:

Q: How does the automatic tension control system benefit the coating process?

A: The automatic tension control ensures consistent web tension throughout the coating process, minimizing wrinkles, misalignment, or breakage in the substrate. This results in uniform coating quality and reduces material waste, leading to higher overall efficiency.

Q: What types of materials can be coated with this machine?

A: This paper coating machine is designed for coating a variety of substrates, including paper, board, and film. The adjustable coating width and precision knife-over-roll head accommodate different grades and thicknesses for diverse industrial applications.

Q: When is installation support available for this machine?

A: Installation support is provided upon purchase. Skilled technicians guide you through setup, calibration, and initial trials to ensure optimal operation from the start, regardless of your location.

Q: Where can after-sales service be accessed?

A: After-sales service for the paper coating machine is available worldwide. Customers can access maintenance, troubleshooting, and spare parts support through the manufacturers established global channels.

Q: What safety features are included to protect operators?

A: Operator safety is prioritized with features like emergency stop buttons and safety covers, which restrict access to moving parts and allow immediate shutdown in case of emergencies.

Q: How does the humidification system enhance coating performance?

A: The humidification system maintains optimal environmental conditions around the coating area, preventing static buildup and ensuring consistent adhesive application, especially in low-humidity climates.

Q: What are the main benefits of using this automatic paper coating machine?

A: Benefits include high precision, energy-efficient performance, reduced labor due to automation, quiet operation, robust construction, and dependable service supportmaking it a reliable choice for demanding industrial coating tasks.
